TECHNICAL DATA:

• Mechanical speed STROKES/1’ max. 10
• Power absorption (max.) KW 7.6 (Hot-melt + 3.5)
• Air consumption Nl/1’ 705
• Air pressure bar 6
• Gross weight kg ~3400
• Net weight kg ~2500
• Weight lifted kg max. 50

#	Size range	min.	max.
1	A	20	545
2	B	12	70
3	C	50	200
4	E	-	1016
4	F	-	1219
4	di	200	550
4	ei	120	350
4	fi	120	350
4	di+ei	-	900
